Basic product information
Borö TIDA accumulator tank
A modern rectangular PUR-insulated tank in 60 or 70 modules
The front has two recessed thermometers and is equipped with a drain valve. With its curved white front and top connections, it provides an attractive, concealed pipe installation that allows it to blend into visible spaces. Prepared for an electric heating element from Borö.
Borö TIDA-200L/A, Borö TIDA-300L/A and Borö TIDA-500L/A
Used to increase volume in combination with a heat pump or another heat source. To create a more efficient system and even out the supply temperature
as well as minimize knocking noises from the heating system.
Model TIDA-200L/A or TIDA-300L/A or TIDA-500L/A
Tank Buffer and volume tank
Dimensions WxDxH 600x637x1170 mm or 600x637x1572 mm or 695x747x1749 mm (Curved front)
Volume 204 Liters or 293 Liters or 478 Liters
Operating pressure Radiator 3 Bar
Weight 65 kg or 88 kg or 113 kg
Outer casing White-painted sheet metal
Connection Top
Borö TIDA-300L/BR20 and Borö TIDA-500L/BR25
The enlarged-surface stainless steel domestic hot water coil offers a good alternative to a water heater without reducing the volume on the radiator side. This provides a flexible solution for most households.
Used to increase volume in combination with wood-fired boilers, pellet boilers, water-jacketed wood stoves or fireplaces, chip boilers, solar collectors or heat pumps or another heat source, as well as for domestic hot water production.
Model TIDA-300L/BR20 or TIDA-500L/BR25
Tank Coil tank
Dimensions WxDxH 600x637x1614 mm or 695x749x1766 mm (Curved front)
Volume 293 Liters or 478 Liters
Volume water heater 12 Liters or 15 Liters
Operating pressure Radiator 3 Bar
Operating pressure water heater 10 Bar
Weight 108 kg or 130 kg
Outer casing White-painted sheet metal
Connection Top
Equipment TIDA-300L/B20 20-meter stainless steel hot water coil, Ø22 mm, 3.3 m², including 3 top pipes for BIV shunt or 3-way shunt (1 pipe is plugged). Equipment TIDA-500L/B25 25-meter stainless steel hot water coil, Ø22 mm, 4.0 m², including 3 top pipes for BIV shunt or 3-way shunt (1 pipe is plugged).
Borö TIDA-300L/BR20/SOLR8 and Borö TIDA-500L/BR25/SOLR12
The enlarged-surface stainless steel domestic hot water coil offers a good alternative to a water heater without reducing the volume on the radiator side. The tank is also equipped with an 8- or 12-meter stainless steel solar coil. This further expands the tank’s applications to suit most households.
Used to increase volume in combination with a heat pump, solar collectors or another heat source, as well as for domestic hot water production.
Model TIDA-300L/BR20/SOLR8 or TIDA-500L/BR25/SOLR12
Tank Coil tank with solar coil
Dimensions WxDxH 600x637x1614 mm or 695x749x1766 mm (Curved front)
Volume 293 Liters or 478 Liters
Volume water heater 12 Liters or 15 Liters
Operating pressure Radiator 3 Bar
Operating pressure water heater 10 Bar
Weight 119 kg or 143 kg
Outer casing White-painted sheet metal
Connection Top
Equipment TIDA-300L/BR20/SOLR8 20-meter stainless steel hot water coil, Ø22 mm, 3.3 m², 8-meter stainless steel solar coil, Ø22 mm, 1.3 m², including 3 top pipes for BIV shunt or 3-way shunt (1 pipe is plugged). Equipment TIDA-500L/BR25/SOLR12 25-meter stainless steel hot water coil, Ø22 mm, 4.0 m², 12-meter stainless steel solar coil, Ø22 mm, 2.0 m², including 3 top pipes for BIV shunt or 3-way shunt (1 pipe is plugged).
